FM8000 Metal Cutting Extractor

$13,750.00

Our AAFM8000 Metal cutting extractor is designed to effectively filter Fiber Cut Dust and Fumes, including welding. This machine uses 6 x PEFE filters which are pulsed with an air cannon to keep them clean giving a long life up to 3 years. This machine is ideal for Fiber Metal Cutting laser machines up to…

Quantity:

Description

Our FM8000 Metal laser cutting purifier is designed to effectively filter laser metal cutting fumes. Fitted with first-class advanced motors and our self- braking balance correction technology reduces noise, and the large air volume and high negative pressure ensure better dust absorption.

This machine uses 6 x PEFE filters which are pulsed with an air cannon to keep them clean giving a long life in excess of 3 years. Our low-cost filters make this the most affordable filtration system on the market to date. Remote start available. Check the prices here (insert link to filter replacement page – opens a new page).

Filters included and available to purchase:

6 x PEFE filters – Expected life is up to 3 years.

Pulse canon included.

Dual Inlets.

How it works:

Our 11.5Kw motor is used for stable operation, and long-lasting service life. It can work continuously for 24 hours with no down time.

The sealed high-precision membrane filter PEFE membrane material is used, and the debris filtration accuracy is higher than 0.3um99.9%, and the filtration rate meets zero dust workshop standard.

This model uses a 11.5Kw high efficiency extraction fan. The new design, the fan can be adjusted in automatic and manual modes for greater control over dust removal.

Recommended for:

Metal Cutting Fiber Laser machines up to 6000mm x 2500mm.

Rust removal bays.

Fiber Welding Bays.

Model Name: AAFM8000

Size: 920mm x 1050mm x 2130mm

Package Size: 1620mm x 1450mm x 2350mm

Weight: 620kgs

Power: 11.5Kw

Voltage: 415V 3Phase

Volume Processing: 8000m3/h
Efficiency rated at 99%
Inlet Spiggot Diameter options are 150mm, 200mm & 250mm
2 x 4.5 Meters of hose included
4 hose clamps included
Dual Spiggot inlet
Timber crated packaging and plastic wrapped prepared.

Warranty: 2 years
Meets Australian Electrical Requirements
Purchase – Rent or Rent to buy options available
International Domestic shipping available
Installation set up available at an extra cost
